HLAY5-EA42 NC Red
Cap/operator or lens colour : Red Fixing collar material : Plastic Shape of signaling unit head : Round Type of operator : Spring return Operator profile : Red flush Contacts type and composition : 1 NC Contact operation : Slow-break Contacts usage : Standard contacts Mechanical durability : 1000000 cycles Connections - terminals : Screw clamp terminals [Ith] conventional free air thermal current : 6 A [Uimp] rated impulse withstand voltage : 6 kV [Ie] rated operational current : 2 A at 380 V, 3.3 A at 220 V, AC-15, 0.5 A at 220 V, 1.1 A at 110 V, DC-13 Electrical durability : 1000000 cycles AC, 200000 cycles DC E-commerce address : Hlay5-pushbuttons-mushroom-and-emergency-stop-pushbuttons-1
Pushbutton, HLAY5, flush, 1 NC, red
Range of product : HLAY5 Device presentation : Complete product Product or component type : Pushbutton Bezel material : Plastic Mounting diameter : 22 mm Head type : Standard
Ambient air temperature for operation : -5…40 °C IP degree of protection : IP40, IP65 with protective cover Standards : IEC 60947-5-1
.png)
Unit Type of Package 1 : PCE
Number of Units in Package 1 : 1
